Description
Print:
Printing Technology: Advanced MicroPiezo® AMC™ print head with ink-repelling coating technology, 8-channel, drop-on-demand, inkjet print headMaximum Print Resolution: 2880 x 1440 dpiMaximum Printable Area:
- Maximum paper width: 17″
- Maximum cut-sheet size: 17″ x 22″
- Minimum cut-sheet size: 3.5″ x 5″
- Maximum printable area: 17″ x 129″
Minimum Ink Droplet Size:
- 3.5 picoliters
- Variable Droplet Technology can produce up to 3 different droplet sizes per print line
Nozzle Configuration: 180 nozzles x 8
Ink:
Ink Type: Ink Type: Pigment-based Epson UltraChrome® HD ink technologyInk Palette: 8-color Photo or Matte Black, Cyan, Vivid Magenta, Yellow, Light Cyan, Vivid Light Magenta, Light Black, Light Light BlackInk Configuration:Auto-Switching Black Ink Technology
- Fully automatic switching between Black ink modes
Ink used during conversion
- Matte to Photo Black approx. 4.6 ml
- Photo to Matte Black approx. 1.6 ml
See Note1Replacement Ink:Epson Intelligent Ink Cartridges
- Cartridge fill volume: 80 ml each color x 9 colors total
Ink cartridge shelf life
- 2 years from printed production date or 6 months after opened
See Note2Fade Resistance / Print Longevity: Color: Up to 200 years1
Black-and-White: Up to 400 years1
General:
Operating Systems:
- Apple macOS® 10.13.x-10.12.x, OS X®: 10.11x-10.7x
- Microsoft® Windows®: 10, 8.1, 7 (32-bit, 64-bit)
Temperature:Operating
- 50° to 95° F (10° to 35° C)
Storage
- -4° to 104° F (-20° to 40° C)
Humidity:Operating
- 20% to 80% (no condensation)
Storage
- 5% to 85% (no condensation)
Sound Level: Approx. 50 dB according to ISO 7779Dimensions: 26.93″(W) x 14.80″(D) x 9.85″(H)Weight: 43 lbSafety Approvals: UL1950, CSA 22.2 950 FDA, EMI: FCC Part 15 subpart B class B, CSA C108.8 class B, AS/NZS 3548 class B
Printer Details:
Printer Language: Epson ESC/P raster photographic drivers
Power:
Rated Voltage: AC 110 – 120VRated Frequency: 50 – 60 HzRated Current: Less than 1.0 A/110 – 120 VPower Consumption:
- Printing: Approx. 21 W
- Sleep Mode: Approx. less than 1.8 W
Connectivity:
Standard Connectivity:
- Hi-Speed USB 2.0 (1 port)
- 100Base-T Ethernet (1 port)
- Wi-Fi CERTIFIED™ (802.11n only)3
- Wi-Fi Direct3
- Epson iPrint™ Mobile App, Apple® Airprint™, Google Cloud Print™
Paper Handling:
Maximum Paper Size:Main top-loading feeder
- Up to 17″ x 22″
- Up to 120 sheets plain; 30 photo
Roll paper (optional)
- 17″ roll, 2″ or 3″ core
Front media path
- Up to 17″ x 22″
- Single sheet manual feeder, designed for fine art paper and media up to 1.3 mm thick
Borderless Sizes: 3.5″ x 5″, 4″ x 6″, 5″ x 7″, 8″ x 10″, A4 (8.3″ x 11.7″), letter (8.5″ x 11″), 11″ x 14″, B (11″ x 17″), A3 (11.7″ x 16.5″), Super B (13″ x 19″) and C (17″ x 22″) sizes
