Description
Description
- Human-machine interface touch screen operation ,it only takes a few seconds to replace the book of different sizes, and the position adjustment of each process can be completed by entering the thickness of the inner core of the book.
- Quickly replace a variety of round ridge forming positioning pressure plates and square ridge positioning pressure plates with different radians to complete the combination of square back and round back bookcases and book blocks of different specifications.
- Equipped with infrared grating safety protection device to ensure safety.
- High-speed optical fiber detects the position of the book block, if there is any deviation between the book cover and the book block sleeve:change the coordinate value on the touch screen to eliminate the deviation (several degrees 0.1mm).
- The glue tank can be taken out for pouring or cleaning at any time.
- The machine base is equipped with high-capacity casters for easy leveling, support and movement.
Product Parameters
|
Speed
|
About 720 books/hour
|
|
Max. book size
|
360*360mm
|
|
Min. book size
|
90*60mm
|
|
Book thickness
|
5-65mm
|
|
Gumming roller width
|
360mm
|
|
Machine size
|
1620*1050*1850mm
|
|
Weight
|
570kg
|
Reviews (0)
Related products
Book Binding Machine
Our machine can efficiently and safely use the melted glue to closely bond the semi-finished book pages and covers.
Ensure your efficiency and safety
- Button LCD display ,easy to read, easy to operate.
- Large fan can vacuuming completely and avoid paper scrap go into the glue groove.
- single roller system ensures perfect and firm binding.
- With brand components, quality can assurance.
- According custom need, adjust book finish effect in square or round.
- Sun knife and small milling cutter. Ensure the perfect milling and book binding.
- Stable erect clamping table design, the clamping surface effect is good, suitable for various thickness cover, book shaping effect is better.
Fully Automatic Book Case Making Machine
This, machine is applied in covering and pressing various notebooks, photo books (photo album), folders, certif icates andhardcover books. This process is f inished easily at twice on both sides at the same time by one operator. It is the g1ood partner of post-press, especiallythe digital postpress.
Feature And Characteristics:
- Adopting PLC operating system;
- Use hot glue (animal glue / Jelly glue), cold glue;
- Replace products, fast adjustment speed control
- The thickness of the cardboard automatiically:
- Adjust the size by rotating the ha die wheel;
Hydrullic Paper Cutter
Multifunctional operating system with multiple cutting modes
Normal mode/Equal division mode/Programming mode/Fully automatic cutting
Direct cutting by inputting data
Circular cutting by inputting the same or different sets of data
Inputting different data to meet multiple cutting requirements
Automatic cutting according to pre-recording without pressing the cutter button
- Hydraulic clamp and cutting Drive
- Heavy duty structure,higher accuracy
- CE Standard
- safety latch, safety light curtain
- Double Auto Breaker satety design
- centralized control circuit for easy maintenance
- Auto Measure function
- Foldable and disasseble back table
- Backgauge motor: Step motor
- Backgauge speed:3.5m/minute
